Product Details
Place of Origin: Shanghai, China
Brand Name: Neardi
Model Number: LPA3588
Document: LPA3588 Embedded Computer V....1.pdf
Payment & Shipping Terms
Minimum Order Quantity: 1 piece
Price: Negotiable
Packaging Details: 33.5×19×9 cm
Delivery Time: 7 days
Payment Terms: L/C, D/A, D/P, T/T
Supply Ability: 10000/pieces/mon
SOC: |
RK3588 |
Supplier Type: |
OEM/ODM |
CPU: |
8nm, 4*A76+4*A55 |
GPU: |
ARM Mali-G610 MC4 |
NPU: |
6 TOPS |
VPU: |
8K |
DDR: |
LPDDR4, 4GB/8GB/16GB |
EMMC: |
EMMC 5.1, 32GB/64GB/128GB |
Working Temperature: |
-10 ~ 70℃ |
PCB Interface: |
B2B |
OS: |
Android/Buildroot/Debian/Ubuntu |
Embedded: |
Yes |
Application: |
Medical Equipment/Networking And NAS |
SOC: |
RK3588 |
Supplier Type: |
OEM/ODM |
CPU: |
8nm, 4*A76+4*A55 |
GPU: |
ARM Mali-G610 MC4 |
NPU: |
6 TOPS |
VPU: |
8K |
DDR: |
LPDDR4, 4GB/8GB/16GB |
EMMC: |
EMMC 5.1, 32GB/64GB/128GB |
Working Temperature: |
-10 ~ 70℃ |
PCB Interface: |
B2B |
OS: |
Android/Buildroot/Debian/Ubuntu |
Embedded: |
Yes |
Application: |
Medical Equipment/Networking And NAS |
Product Parameters
Function
|
Description
|
SOC
|
RK3588, 8nm, 4*A76+4*A55
|
GPU |
ARM Mali-G610 MC4;OpenGL ES 1.1/2.0/3.1/3.2;Vulkan 1.1/1.2
OpenCL 1.1/1.23/2.0; |
NPU |
6 TOPS, int4/int8/int16/FP16/BF16/TF32
|
VPU
|
Decode: H.265/H.264/AV1/VP9/AVS2, 8K60FPS
Encode: H.264/H.265, 8K30FPS
|
DDR
|
LPDDR4, 4GB/8GB/16GB
|
eMMC
|
eMMC 5.1, 32GB/64GB/128GB
|
PMU |
RK806
|
OS | Android / Buildroot / Debian / Ubuntu |
Hardware Interface
|
|
Power input
|
DC 9V - 36V |
USB
|
3*Type-A USB3.0 HOST,
1*Type-c USB3.1 OTG 3*Type-A HDMI 2.0, |
Display output |
1*DP,
1*Duel channel LVDS |
Audio |
1*φ3.5mm audio out,
1*φ3.5mm microphone, 2*Speaker output with 10W@8Ω |
Video input
|
1*HDMI2.0 Input,
8*AHD input up to 1920*1080@30fps per channel |
PCIe |
1*mini PCIe for 2G/3G/4G/5G LTE module,
1*mini PCIe for AI cards (optional) |
M.2 |
M.2 NGFF ( M-KEY ) PCIE V2.1 *4 with NVMe SSD supported
|
SATA | 1*SATA3.0 |
SD card
|
Compatible with SDIO 3.0 protocol, system boot up supported
|
SIM card | Micro sim slot for Mini-PCIe 4G LTE module |
RJ-45 |
2*10/100/1000 Ethernet
|
Connectivity |
2*Uart, 2*CANBUS, 4*RS232, 1*RS485
|
Wiki Documentation: | http://wiki.neardi.net/docs/welcome |
GitHub: | https://github.com/neardiGitLab: https://gitlab.com/neardiSDK |
Repository: | https://gitlab.com/neardi-linux |
Forum: | https://forum.neardi.com |
Video Tutorials: | https://www.youtube.com/@neardichannels |
