Place of Origin: Shanghai, China
Brand Name: Neardi
Model Number: LPM3588
Payment & Shipping Terms
Minimum Order Quantity: 1 piece
Price: Negotiable
Packaging Details: 33.5×19×9 cm
Delivery Time: 7 days
Payment Terms: L/C, D/A, D/P, T/T
Supply Ability: 10000/pieces/mon
Operating Temperature: |
-10 ~ 70℃ |
Dimensions: |
205*120.5*57.7 |
CPU: |
4A76 + 4A55 |
VPU: |
8K |
PCB Interface: |
B2B |
Application: |
Real-time Data Processing And Machine Vision. |
GPU: |
ARM Mali-G610 MC4 |
OS: |
Android/Buildroot/Debian/Ubuntu |
Operating Temperature: |
-10 ~ 70℃ |
Dimensions: |
205*120.5*57.7 |
CPU: |
4A76 + 4A55 |
VPU: |
8K |
PCB Interface: |
B2B |
Application: |
Real-time Data Processing And Machine Vision. |
GPU: |
ARM Mali-G610 MC4 |
OS: |
Android/Buildroot/Debian/Ubuntu |
Introducing the LPM3588 intelligent computer, meticulously crafted around the Rockchip RK3588 chip. This advanced device features a full aluminum, fanless design and an innovative internal structure that efficiently conducts heat from key components like the CPU and PMU to the external casing. This ensures optimal performance in harsh environments, making it ideal for a range of industrial applications.
The LPM3588 comes equipped with 2 Type-A USB 3.0 HOSTs for connecting multiple USB cameras and 1 mini-PCIe interface for adding a 4G module or NPU computing card based on RK1808. It supports dual-band WIFI 6, BT5.0, 5 Gigabit Ethernet ports, CANBUS, RS485, and other communication modules. The device also provides 2 HDMI outputs, 1 HDMI 2.0 input, and 1 DP output, supporting multi-screen independent displays.
Supporting multiple operating systems such as Android, Buildroot, Debian, and Ubuntu, the LPM3588 offers high performance, reliability, and scalability. The open system source code allows users to develop and customize their applications. Our company provides comprehensive technical support to help developers and enterprise users efficiently complete R&D and expedite the market launch of their products.
| Function | Description |
| CPU |
8nm advanced process technology with an 8-core 64-bit architecture (4A76 + 4A55), offering high performance with low power consumption. |
| GPU | ARM Mali-G610 MC4 GPU, featuring a dedicated 2D graphics acceleration module. |
| NPU | 6TOPS computing power for AI-related tasks. |
| VPU | Capable of 8K video encoding and decoding, as well as 8K display output |
| DDR | LPDDR4, with options for 4GB/8GB/16GB. |
| eMMC | eMMC 5.1, with options for 32GB/64GB/128 GB. |
| PMU | RK806 |
| OS | Android / Buildroot / Debian / Ubuntu |
| Hardware Interface | |
| Power input | DC12V - 3A (DC Jack 5.5*2.1mm / PH2.0 wafer connector) |
| USB | 2*Type-A USB3.0 HOST |
| Display output | 2*Type-A HDMI 2.1 up to 8K@60fps or 4K@120fps 1*DP1.2 2Lane Output |
| Display in | 1* HDMI-IN(4K@60fps),Supports HDCP 2.3 |
| Audio | φ3.5mm earphone Jack with Mic in L/R audio out |
| Net work | 5* 10/100/1000Mbps Ethernet；1* 10/100Mbps Ethernet |
| Size | L*W*H(mm) 205*120.5*57.7 |
| Operating Temperature | -10 ~ 70℃ |
| Weight Approximately | 1083 g (excluding peripherals) |
The Embedded Computer product comes with reliable technical support and services to ensure smooth and efficient operation. We provide:
- Comprehensive product documentation and guides for easy installation, configuration, and maintenance.
- Online resources such as FAQs, knowledge base, and forums to address common issues and concerns.
- Expert technical support from our knowledgeable and experienced team via phone, email, or chat.
- Advanced diagnostic tools and remote troubleshooting assistance to quickly identify and resolve any problems.
- Regular software updates and patches to ensure optimal performance and security.
We are committed to delivering the highest level of customer satisfaction and support for our Embedded Computer product.
Product Packaging:
Shipping:
Q: Where is this embedded computer manufactured?
A: This embedded computer is manufactured in Shanghai, China.
Q: What is the brand name of this embedded computer?
A: The brand name of this embedded computer is Neardi.
Q: What is the minimum order quantity for this product?
A: The minimum order quantity for this product is 1 piece.
Q: What are the available payment terms for this product?
A: The available payment terms for this product are L/C, D/A, D/P, and T/T.
Q: What is the delivery time for this product?
A: The delivery time for this product is 7 days.
Q: What are the packaging details for this product?
A: The packaging details for this product are 33.5×19×9 cm.
Q: What is the supply ability for this product?
A: The supply ability for this product is 10000 pieces per month.
Q: Is the price negotiable for this product?
A: Yes, the price for this product is negotiable.
